360°rotation and 230°force range, built-in ball structure, uniform force distribution, smooth rotation.
When the direction of force changes, the lifting ring rotates with the direction of force without twisting.
Specification
|
Product code |
WLL |
THREAD |
Dimensions |
TORQUE |
N.W. |
||||||||
|
T |
M |
E |
PITCH |
A |
B |
C |
D |
F |
G |
K |
Nm |
kg |
|
|
mm |
mm |
mm |
|||||||||||
|
RP003-M8 |
0.4 |
M8 |
12 |
1.25 |
30 |
43.5 |
54 |
12 |
97.5 |
40 |
37 |
40 |
0.44 |
|
RP003-M10 |
0.6 |
M10 |
19 |
1.5 |
30 |
43.5 |
54 |
12 |
97.5 |
40 |
37 |
40 |
0.45 |
|
RP003-M12 |
0.7 |
M12 |
19 |
1.75 |
30 |
43.5 |
54 |
12 |
97.5 |
40 |
37 |
40 |
0.45 |
|
RP003-M14 |
1.25 |
M14 |
31.8 |
2 |
30 |
43.5 |
54 |
12 |
97.5 |
40 |
37 |
100 |
0.45 |
|
RP003-M16 |
1.5 |
M16 |
31.8 |
2 |
30 |
43.5 |
54 |
12 |
97.5 |
40 |
37 |
130 |
0.48 |
|
RP003-M18 |
1.9 |
M18 |
30 |
2.5 |
34 |
54.5 |
78 |
16 |
132.5 |
59 |
54.5 |
170 |
1.35 |
|
RP003-M20 |
2 |
M20 |
30 |
2.5 |
34 |
54.5 |
78 |
16 |
132.5 |
59 |
54.5 |
170 |
1.4 |
|
RP003-M22 |
2 |
M22 |
30 |
2.5 |
34 |
54.5 |
78 |
16 |
132.5 |
59 |
54.5 |
170 |
1.4 |
|
RP003-M24 |
3.15 |
M24 |
30 |
3 |
34 |
54.5 |
78 |
16 |
132.5 |
59 |
54.5 |
280 |
1.4 |
|
RP003-M27 |
4 |
M27 |
38.1 |
3 |
40 |
67 |
93 |
20 |
160 |
70 |
64.5 |
500 |
2.35 |
|
RP003-M30 |
5 |
M30 |
35 |
3.5 |
40 |
67 |
93 |
20 |
160 |
70 |
64.5 |
600 |
2.5 |
|
RP003-M33 |
7.5 |
M33 |
50 |
3.5 |
51 |
95 |
111 |
22 |
206 |
79 |
74 |
600 |
3.8 |
|
RP003-M36 |
10 |
M36 |
54 |
4 |
51 |
95 |
111 |
22 |
206 |
79 |
74 |
600 |
3.9 |
|
RP003-M39 |
10 |
M39 |
58 |
4 |
51 |
95 |
111 |
22 |
206 |
79 |
74 |
800 |
4 |
|
RP003-M42 |
13 |
M42 |
63 |
4.5 |
65 |
108 |
122.5 |
26 |
230.5 |
93 |
85 |
800 |
5.9 |
|
RP003-M45 |
13 |
M45 |
68 |
4.5 |
65 |
108 |
122.5 |
26 |
230.5 |
93 |
85 |
800 |
6 |
|
RP003-M48 |
14 |
M48 |
68 |
5 |
65 |
108 |
122.5 |
26 |
230.5 |
93 |
85 |
800 |
6.15 |
|
RP003-M56 |
20 |
M56 |
84 |
5.5 |
70 |
120 |
158 |
32 |
278 |
105 |
95 |
900 |
10 |
1. 360 ° rotation and 230 ° force range.
Built-in ball structure, uniform force distribution, smooth rotation.
2. 4 times the safety factor.
The load that can be lifted varies depending on the direction of force, but the 4 times safety factor is guaranteed.
3. Complete thread specifications and a wide range of rated loads.
Customized thread size, length, type, etc are available.
4. Easy to install.
With a hexagonal design for the lifting ring base, allowing for easy installation of the lifting point onto the heavy object.
Product Details
Customization
BOLT CUSTOMIZATION
- Bolt surface can be designed by customer's requirement. Most common surfaces are black oxidation and Galvanized.
- Different bolt length are available.
STAMPING CUSTOMIZATION
- Body stamping content and stamping way are optional.
BODY CUSTOMIZATION
- Different body colors are available.
PACKING CUSTOMIZATION
- Single plastic bag or cartons can be specially designed by customer's requirements.
- Like color, logo, etc.
- Can provide design service for customers.
